D365 Portals : X-Content-Type-Options Header

In an earlier post I provided a few of options for dealing with JavaScript code in your D365 portals. The second of those options was to modify the extension of the file that is attached to the Web File Note so it isn’t blocked as an attachment.

With a recent upgrade to the portal it appears that Microsoft have now closed the door on that particular option and for good (security) reasons. They have now added the X-Content-Type-Options header to the response with a setting of nosniff. This means that when the browser detects a difference between the file extension and the MIME type then the browser generates an error and the script is not loaded.

This means that in order to use custom JavaScript files in your D365 portals you are left with either option #1 or option #3 from my previous post, or use a CDN.

Advertisements

D365 – Field Service – Debugging Booking Rules

Booking Rules in D365 are generated as Web Resources (JavaScript) to show warning or error messages to the scheduler. The problem with debugging these web resources is that the files are loaded dynamically which makes them a little harder to debug. When you have complex or a large number of booking rules you have a few options to assist you with debugging.

  • console.log – this is the most basic option but allows you to write out values to the debug console of the browser. This can give you some information may not pinpoint the exact line were an issue is occurring.
  • debugger statement – this will cause your web resource to load into the dev tools of the browser and stop on the line where the statement exists. This at least allows you to continue on with debugging but you need to remember to remove it before you publish the resource into a production environment.
  • sourceURL comment – if you place the following comment at the end of your script file – after the closing curly brace – the file will then show in the sources tab.
//# sourceURL=filename.js

You can replace filename.js with any filename you like, e.g. BookingRules.js. When you browse your Sources in the Dev Tools you will find the file and be able to put in breakpoints as required. You will need to force the booking rules to run at least once for the file to be loaded. The other good point about this technique is that you don’t need to remove the comment for the file when its moved to a production environment.

This works for Chrome, Firefox and the new Chromium Edge browsers.

D365 Portals – Custom JS

There are a few ways you can host your custom JavaScript for your D365 portal within the portal configuration.

  1. Circumvent the System Settings and allow JS files to be uploaded to D365. The default system settings disallow JS files from being uploaded to D365. If you remove the JS extension from this list you can upload the files to D365. However, this is not ideal because it exposes your whole environment to malicious JS files potentially being uploaded.
  2. Change the file extension on your JS files. Although D365 won’t allow JS files because of the reason mentioned above, you can change the extension of the file, for example, .AXD. You are now able to attach the file to the Notes in your Web File and you can still give your web file a Partial URL ending in .JS. The JavaScript file will still be accessible as normal through the SCRIPT tag.
  3. My preferred option uses a similar technique to that used to return JSON responses from FetchXML queries in a Web Template. If we enter the JavaScript code directly in a Web Template and set the MIME Type to application/javascript we can use that Web Template in a page, with no header/footer, to serve up our custom JavaScript.
  4. Step 1. Create the Web Template

    Step 2. Create the Page Template with no header/footer

    Step 3. Create the JavaScript ‘Page’

    Step 4. Create the a regular Portal Page and embed the SCRIPT tag to request the custom JavaScript

    The result is that the JavaScript file is served from D365 and the functions run as normal.

    Obviously, if you have access to a CDN then you can upload them to there and add the necessary tags to your portal Pages, Web Templates etc.

D365, Flow and Twilio – Part 2

In my previous post I walked through the process of setting up your Twilio account to provide two factor authentication for registering with a Microsoft D365 portal. In this part I will show you how to verify that the verification code is correct. This post assumes you have created a page that can be used to enter the verification code you requested in the previous post and the verification code is sent to the D365 Contact record.

The first step is to create a trigger to do the verification check when the D365 Contact record is updated. We only want the verification to be performed under specific circumstances; In this case we put a condition to check the field we are storing the verification code in has a value and the Mobile Phone Confirmed field is currently false. For the purposes of the demo I am using the Fax field to store the verification code but you can create your own custom field to hold the code.

Step-1

If the Contact record is being updated for some other reason then the verification is not performed and the Flow just exits. If we are doing a Mobile Phone verification then we need to generate a GET request to the Twilio. Using this API we need to provide a couple of header values. The first is normal Content-type (application/json) and the important one is the X-Authy-API-Key which is available in the General Settings of your Verify Project.

Step-2

The dynamic values we pass to the API are the Mobile Phone and Fax (Verification Code) from the Contact record. The GET request will return a response that we parse using the Parse JSON Action. To fill out the Schema box I put the request we created (above) into Postman to get the response. Selecting the Use sample payload to generate schema option I was able to paste in the response and generate the schema.

Step-3a

For the Content field we just use the Body of the response we receive from the HTTP GET request.

Step-3

The next step is to check what response we have received as a Flow Condition so we can determine whether to update the record.

Step-4

Again, using the response from Postman you can determine what key value pairs are returned from the GET request. The screenshot below shows an example of a failure (Status: 404 Not Found) but the structure of the response is still the same as a successful response.

Step-4a

If the Condition has success equal to true, then we can update the Contact record to confirm the mobile phone number has been confirmed. Click on the Show advanced options to find the relevant field.

Step-5

Step-5a

We have now completed the steps of using Microsoft Flow and Twilio to confirm the mobile phone number for a Contact within the D365 Portal.

D365 Product Bundles – max number of products

By default, D365 CE has a limit of 15 Products that can be added to a Product Bundle. When you try to add a 16th you get presented with a nice warning message (above). Fortunately, this is one of the many configurable items of D365. In the System Settings, navigate to the Sales tab and change the Set maximum products in a bundle setting to a higher value.

D365, Flow and Twilio

In this post I will walk through the steps to use Microsoft Flow and Twilio to provide two factor authentication for registering with a Microsoft D365 portal. For the purpose of this post I am not actually going to go through the portal registration process as there are plenty of posts out there on how to configure the D365 portal for registration. Instead, I will simulate the process by creating my own Contact record and using Flow to deal with the messaging.

The first task is to sign up for a Twilio account. The great thing is they provide free trial to check the services are going to meet your needs. For our needs we are creating a Verify project.

Step-1

Step-2

The next step is to verify a phone number against your own Twilio account. This option also allows you to set 2FA on your own Twilio account.

Step-3

We then add a Friendly Name for the application.

Step-4

Add a phone number to make your first request

Step-5

Pressing the Make Request button will send the message to the designated mobile number with the Friendly Name of your project in the content of the SMS message. Make sure you select the correct Country Code!

Step-6

To verify the code supplied in the SMS message you can complete the process by supplying the verification code.

Step-7

If you supplied the correct verification code then you will get the following response.

Step-8

Having completed the setup for the Verify project we can now turn our attention to the Microsoft Flow configuration. The process will need to send the verification code when a new Contact record is created that contains a value in the Mobile field.

The first step is to create a trigger that is going to start the operation. For this we need a Dynamics 365 trigger called When a record is created.

Step-1Step-2

Make sure you give your trigger an appropriate name before you add any other actions because this can’t be changed once actions are attached to the trigger.

Step-3

Enter the name of the D365 Organization and the select the relevant entity for the trigger, in our case its the Contacts entity. After that we add our first Action which is a Condition to check that the Mobile Phone field has a value. If it doesn’t the workflow will just finish.

Step-4

If a Mobile Phone number is supplied in the new Contact record then we can create the request to our Twilio application. This is done by creating an HTTP Action that uses the POST method to send the request.

Step-5

Twilio has some good documentation on the API requests that can be made for the Verify API, including simple examples. – Verify Phone Verification API. Using this API we need to provide a couple of header values. The first is normal Content-type (application/json) and the important one is the X-Authy-API-Key which is available in the General Settings of your Verify Project.

Step-6

The POST body names to contain the key-value pairs for parameters listed in the API documentation. For the phone_number we select the dynamic value from the Contact Mobile Phone field. To test our Flow we can use the Test option and create a quick Contact record in D365.

Step-7

Step-8

Once you click the Test button then you need to create your Contact record and fill out the Mobile Phone field. The mobile phone number can be entered without spaces, with spaces or with hyphens.

Step-9

You should then get a response on your Flow to say that everything ran successfully, plus you should get you SMS on the mobile phone you entered in the Contact record with a verification code.

Step-10

You can also review the Flow history within the Flow dashboard, under My Flows, to see which requests were successful. Opening the specific run will provide details of when the trigger was fired, which Actions were completed and details about the POST request and response.

Step-11

In my next post I will provide a walk through of how to verify the code that was supplied in the SMS message.

D365 Authentication – connect my apps

With the constant push to make data more secure D365 now includes Application Users that can be configured to allow access to D365 from external applications. There are numerous articles around explaining how to create your Application User in D365 using Azure AD App Registrations – this one from PowerObjects has a good explanation of steps required to achieve this.

In this post I wanted to briefly describe the next steps for using that authentication method in your app to perform CRUD operations. To demonstrate this I created a simple Console App to connect to a D365 instance and perform some simple operations using both the OrganizationWebProxyClient and the CrmServiceClient. For reference, I added a package from NuGet called Microsoft.CrmSdk.XrmTooling.CoreAssembly which contains the official Microsoft.Xrm.Tooling.Connector assembly. The same NuGet package also contains the Microsoft.CrmSdk.CoreAssemblies dependency which contains the Microsoft.Xrm.Sdk.dll. Within the console app I created a class that manages to authentication.

using Microsoft.IdentityModel.Clients.ActiveDirectory;
using System;
using System.Collections.Generic;

namespace OrgService.Connect
{
    class AuthHook : Microsoft.Xrm.Tooling.Connector.IOverrideAuthHookWrapper
    {
        // In memory cache of access tokens
        Dictionary<string, AuthenticationResult> accessTokens = new Dictionary<string, Microsoft.IdentityModel.Clients.ActiveDirectory.AuthenticationResult>();

        public void AddAccessToken(Uri orgUri, Microsoft.IdentityModel.Clients.ActiveDirectory.AuthenticationResult accessToken)
        {
            // Access tokens can be matched on the hostname,
            // different endpoints in the same organization can use the same access token
            accessTokens[orgUri.Host] = accessToken;
        }

        public string GetAuthToken(Uri connectedUri)
        {
            // Check if you have an access token for this host
            if (accessTokens.ContainsKey(connectedUri.Host) && accessTokens[connectedUri.Host].ExpiresOn > DateTime.Now)
            {
                return accessTokens[connectedUri.Host].AccessToken;
            }
            else
            {
                accessTokens[connectedUri.Host] = GetAccessTokenFromAzureAD(connectedUri);
            }
            return accessTokens[connectedUri.Host].AccessToken;
        }

        private AuthenticationResult GetAccessTokenFromAzureAD(Uri orgUrl)
        {
            string organizationUrl = "https://myD365instance.crm6.dynamics.com";
            string clientId = "00000000-0000-0000-0000-000000000001";    // This is the Application ID from your App Registration
            string appKey = "<the client secret for your app>";          // The Client Secret from your App Registration
            string aadInstance = "https://login.microsoftonline.com/";
            string tenantID = "00000000-0000-0000-0000-000000000001";    // The GUID of your Azure Tenant ID. See the article above for details on finding this value.

            ClientCredential clientcred = new ClientCredential(clientId, appKey);
            AuthenticationContext authenticationContext = new AuthenticationContext(aadInstance + tenantID);
            AuthenticationResult authenticationResult = authenticationContext.AcquireToken(organizationUrl, clientcred);

            accessTokens[new Uri(organizationUrl).Host] = authenticationResult;

            return authenticationResult;
        }
    }
}

To access the D365 instance using the OrganizationWebProxyClient we can use the following code

                string organizationUrl = "https://myD365instance.crm6.dynamics.com";

                var hook = new AuthHook();

                var requestedToken = hook.GetAuthToken(new Uri(organizationUrl));

                using (var webProxyClient = new OrganizationWebProxyClient(new Uri($"{organizationUrl}/XRMServices/2011/Organization.svc/web"), false))
                {
                    webProxyClient.HeaderToken = requestedToken;

                    // Test with a basic WhoAmI request first
                    OrganizationRequest request1 = new OrganizationRequest()
                    {
                        RequestName = "WhoAmI"
                    };
                    OrganizationResponse response1 = webProxyClient.Execute(request1);

                    // We are also able to create an instance of the OrganizationService and run queries against it
                    IOrganizationService organizationService = webProxyClient as IOrganizationService;

                    Entity entity = organizationService.Retrieve("account", new Guid("92348762-0D32-E611-80EC-B38A27891203"), new Microsoft.Xrm.Sdk.Query.ColumnSet("name", "preferredcontactmethodcode"));

                }

Using the Microsoft.Xrm.Tooling.Connector we require a slightly different approach when using the authenticated Application User. It still uses the AuthHook class but through the AuthOverrideHook property. This uses the same AuthHook object we created earlier for the OrganizationWebProxyClient.

                // Register the hook with the CrmServiceClient
                CrmServiceClient.AuthOverrideHook = hook;

                // Create a new instance of CrmServiceClient, pass your organization url and make sure useUniqueInstance = true!
                var client = new CrmServiceClient(new Uri(organizationUrl), useUniqueInstance: true);

                // Test with a basic WhoAmI request first
                OrganizationRequest request2 = new OrganizationRequest()
                {
                    RequestName = "WhoAmI"
                };
                OrganizationResponse response2 = client.Execute(request2);

                Entity entity1 = client.Retrieve("account", new Guid("92348762-0D32-E611-80EC-B38A27891203"), new Microsoft.Xrm.Sdk.Query.ColumnSet("name", "preferredcontactmethodcode"));
